Start of the Service Mode: Via " " (Dialog Center) –> Service –>
"OK" –> Service Code "8500". Activate menus 1 to 5 via buttons "red", "green", "yellow" "blue" and "i". End the Service Mode: Press button "TXT".
1. Basic Settings
The table on pages 1-11 and 1-12 shows all basic settings in the service mode. In addition all values marked with * must be adjusted according to adjustment
2. Change of the Memory IC402
After changing IC402 all settings in the service mode must be done according to the table "Basic Settings"
3. Hotel Mode
3.1 Activating the Hotel Mode
The Hotel Mode can be activated via Service Mode (menu 1).
Select point of menu "Hotel" with button P- or P+ , with button V- or V+ set to "YES". End the Service Mode.
With activated Hotel Mode:
- only the "SLEEP TIMER" can be selected in the "Dialog Center".
- the last volume setting is stored as the maximum level possible (H.VOL in menu 1 of the Service Mode).
3.2 Deactivating the Hotel Mode
Press and hold button " " on the remote control handset while switching the TV set on with the mains switch. Activate menu 1 via buttons "red". Select point of menu "Hotel" in menu 1 of Service Mode
via button P- or P+ set with button V- or V+ to "NO".
4. Cancelling the Parental Lock Continuously To cancel the parental lock enter the number "7038".
5. ATS Reset (Automatic Tuning System)
Press the power "ON" button while pressing button "i" on the Remote Control –> Language Selection –> Country Selection -> "OK".
The ATS system stops at every station of acceptable reception quality (AFC and coincidence) and stores the station data and the respective
standard automatically. The system then continues searching.
Pressing the "TXT" button stops the ATS function. If ATS will be stopped before storing anyone station, ATS will start again when switching on the TV again.
6. Software Version Number The software version number is shown after ending the service
mode.
7. Presets Press Button "i" to select "Preset" via the Dialog Center –> Service –> "OK" –> "Factory settings", store with "OK".
8. Maximum Programme Number (Reversing Point):
The reversing point will be automatically added to the station table (indication 0000) and can be sorted like each other channel station.
Grundig Lemax TV Service menu
Photo credit : www.inisdesign.com
DAVIO 37 P 37-2201
GBA0702
DAVIO 37 P 37-4201 TOP
GBA0802
GBA0803
DAVIO 37 P 37-4201/5 TOP
GBA1102
DAVIO 51 T 51-4201 TOP
GBA0902
GBA0903
DAVIO 51 T 51-4201/5 TOP
GBA1202
DAVIO 55 T 55-4201 TOP
GBA1002
GBA1003 DAVIO 55 T 55-4201/5 TOP
GBA1302 LEEMAXX 37 P 37-4204 TOP
GBA3202
GBA3203 P 37-1201/5 TOP
GBA4700 T 51-1201/5 TOP
GBA4600 T 55-1201/5 TOP
GBA4500
