Advent Q2016 TV Service Menu

Advent Q2016 TV Service Menu Factory adjustment mode.
1. B+ voltage test
a) Make sure the AC power is 120 V/60 Hz
b) Connect digital voltmeter to B+ test point, receive A-7 signal, set picture control to“MEMORY 2” state, test B+, the test voltage should be 100 V±0.3 V.
2. AGC adjustment
a) Receive 60 dB split field A-7 signal.
b) Use oscilloscope or digital voltmeter to monitor test N201 pin 43 voltage(AGC output).
c) Press R-AGC button, by making use of [←][→] button, increase the value from low to high until the voltage just reach 4.0 V, at this time picture noisy spot should basically disappear, otherwise continue fine tune R-AGC button.
3. Focus adjustment
3. 1 Receive A-12 signal, set user control to “MEMORY 2” state.
3. 2 Adjust FBT’s focus potentiometer, to make the screen’s B area’s focus optimum.
4. Acelerating electrode adjustment method (use A-7 signal)
4.1 Roughly adjust white balance, fix RCUT value, adjust GCUT,BCUT,GDRV,BDRV’s value to make white balance basically normal.
4.2 Set the color to 0, contrast to 30, use oscilloscope to adjust CRT’s red gun’s waveform (see below figure), adjust brightness to make the seventh step’s (the darkest) DC level be 180V, adjust accelerating electrode to make the seventh step slightly light up (just can separate the seventh step and below dark field).

 Photo credit to www.inisdesign.com

4.3 Fine adjust white balance (color temperature: 12000K±8MPCD X=0.270±0.008 Y=0.283±0.008 )
4.4 Set contrast,brightness,color all to 0, adjust BRTN to make A-7’s upper left 2 lattice slightly light up.
5. Horizontal,vertical scan center adjustment
5.1 Item adjustment
VLIN 50Hz V-linearity adjustment
VSC 50Hz Vertical S-correction
VLIS 60Hz V-linearity adjustment
VSS 60Hz Vertical S-correction
5.2 PAL(50 Hz) H-center,V-center adjustment
Receive D35 signal, set user control to “MEMORY 2” state, fine tune V-center VP50, H-center HPOS,
to make picture’s center be in accordance with screen’s center.
5.3 NTSC(60Hz)H-center,V-center adjustment
Receive A6 signal, set user control to “MEMORY 2” state, adjust V-center VP60, H-center HPS to make picture’s center be in accordance with screen’s center.
6. Vertical scan amplitude adjustment
6.1 PAL(50 Hz)V-amplitude adjustment
Receive D35 signal, set user control to “MEMORY 2” state, adjust V-amplitude HIT, make picture’s upper and lower overscanning be screen size’s 8%.
6.2 NTSC(60 Hz)V-amplitude adjustment
Receive A 12 signal, set user control to “MEMORY 2” state, adjust V-amplitude HITS to make picture’s upper and lower overscanning be screen size’s 8%.

Checking point Advent Q2016 TV Service Menu
1. High voltage check
1.1 Connect high voltage meter to CRT’s second anode and GND.
1.2 Receive A-7 signal, set user control to “MEMORY 1” state, the high voltage should be 29.0 kV±1 kV.
1.3 When brightness and contrast be set to minimum (zero beam current), the high voltage should not exceed
32 kV.
2. CRT filament voltage check
Receive A-7 signal, set picture control to “MEMORY 2” state, use effective value voltmeter to test CRT
filament voltage, the reading should be (6.3±0.3)Vrms.
3. X-ray protection check
3.1 Receive A-7 signal, set user control to “MEMORY 2” state.
3.2 Short R554(TP501,TP502), X-ray protection circuit should effect.
4. Picture and sound check
4.1 Receive standard TV signal.
4.2 Making use of picture control buttons to check color,contrast,brightness,sharpness,tint’s control function.
4.3 Making use of sound control buttons to check volume control function.
5. Sub-brightness check
Receive A-7 signal, set color ,contrast,brightness all to 0, picture’s left side first grid slightly lights.
6. This set can produce 28 kinds of testing signal by itself. Press “SLEEP PIC DSP MENU AV” button,
every time you press the buttons, one kind of testing signal will be produced. The first fourteen signals
are NTSC signal and the other fourteen signals are PAL signal. After these signals are cycled for one
time, it will return to original screen.
7. Color purity and convergence check(Use common regulation)
8. AV terminals ( AV IN/OUT check)
9. Other control buttons (on the set and on the remote controller) function check.

Preset the following in factory Advent Q2016 TV Service Menu
1. Picture menu: CONTRAST 100
BRIGHTNESS 50
COLOR 50
SHARPNESS 50
TINT ±00
MODE
MEMORY 4

2. Volume preset to 30.
3. Set OSD language to English.
4. Color system preset to AUTO.
5. TV mode:channel position number 2.
6. Firstly press SHOP OUT D/K SPOUT out-factory button on the factory remote controller,
“ready” will appear, wait for 8-10 seconds, the preset will be stored.
Factory menu
1. Enter into factory menu to operate.
1.1 Press “SLEEP PIC DSP MENU” button(The period of two-press should be within 5 seconds), enter into factory menu.
1.2 Use MENU button to scroll the pages(P1,P2,P3).
1.3 In factory menu status, press SLEEP button to exit.

Advent DV1418A TV Service Menu

Advent DV1418A TV Service mode
Advent DV1418A TDA9377 PS-N2 TDA8357 FACTORY SERVICE ADJUSTMENT
Specific operation: use remote controller
Press “MUTE” => “CALL” => “-\--“ => “CALL” => “MUTE” buttons in sequence to enter into factory mode.
Press [Program+] / [Program-] to select items and press [VOLUME+] / [VOLUME-] key, to make data adjustment
of corresponding factory menus.
Press “EXIT” key to exit factory mode.
Focus adjustment
1. Receive a crosshatch signal.
2. While watching the screen, adjust the FOCUS VR on the FBT to make the vertical and horizontal lines as
fine and sharp as possible.
Geometrical adjustment
Receive NTSC standard complete pattern signal.

Photo credit to www.inisdesign.com

Advent DV1418A TV Service mode Adjustment steps：
a) Adjust VSL, to the centre horizontal line just appears from half bottom shadow.
b) Adjust VAM, to get 92% of vertical picture contents would be displayed on CRT.
c) Adjust VSH, the centre horizontal line corresponds to CRT vertical centre.
d) Adjust SCL, to the linearity of P card field is in proper condition.
e) Adjust HSH, to get the picture horizontal centre correspond to CRT horizontal centre.
Receive NTSC signal and repeat above adjustment.
AGC Adjustment
Receive 60dBμ (1mV) VH colour bar pattern signal.
Select TOP item.
Adjust value, to noise reduce gradually and just disappeared point.
CRT cut off and white balance adjustment
a) CRT cut off adjustment
1. Select item VG2B, then adjust value to 42.
2. PRESS “0” key, when the screen shows”VG2” adjust the SCREEN control on Fly back transformer to
make the screen show alternating flashing characters of “INSIDE HIGH INSIDE LOW”.
b) White balance adjustment
1. Receive a Black and White pattern.
2. Adjust WRP, WRG, WRB items to get colour temperature 9300K ±3 JND.

Advent 27.3251 TV Service Menu

Advent 30.3461 and Advent 27.3251 TV Service mode
Factory mode Instruction
a) In this chassis since there are a great amount of data needed to be set, these setting all are stored
in E2PROM. To reduce the alignment working, use the aligned E2PROM as a female parent to
copy and then use them. Or refer to appendix chart and preset E2PROM value and then use.
b) To conduct the alignment, the power supply should be AC120 V,60 Hz. The whole unit should be
preheated for 30 minutes.
c) To conduct with color purity, convergence, white balance alignment or other alignment relative to
color, the CRT should be degaussed thoroughly.
d) Since this chassis adopts modulization structure, before mounting, every module should be
conducted with alignment.
e The factory menu’s alignment should use XOCECO RC-T03-0A remote control. Press power
switch to turn on the set, in turn press button “SLP-MUTE-AV-MENU” to enter into factory menu.
Press SLP or 0 button to exit. Press MUTE button to preset before Out-factory.

Photo credit : www.inisdesign.com

Alignment procedure, Module alignment Advent 30.3461 and Advent 27.3251 TV Service mode
In all the module alignment, use a normal working TV set as an alignment frock, pull the set’s
corresponding module and keep it as an example. Insert the module wanted to be check,
then apply power to alignment.
a) AV board module
AV interface function check: check all the AV input/outputs function, it should meet the Product
Standard requirements.
b) Digital processing board module
No alignment point, apply the power and check whether S-VIDEO, YCbCr, YpbPr input is normal.
c) Main board
No alignment point. Apply the power and measure “B+” voltage, the reading should be 105V,
check there are no assemble error, the OSD,SVM is normal, and it is OK.
2.2.2 Chassis adjustment
Correctly insert all modules and parts, connect CRT board parts to CRT, apply power and
check B+ voltage, the reading should be 105V. (on J332/J305)
2.2.3 The whole unit adjustment
Be sure the whole unit has been preheated for 30 minutes.
a) Focus adjustment
1) In TV mode receive crosshatch signal, at the same time set SVM to OFF.
2) Adjust FOCUS inductance L306 on Dynamic Power Board to make R323 dynamic focus
voltage be 1KV+/-50V.
3) Adjust FOCUS potentiometer on FBT and CRT to make horizontal and vertical grid both
thinnest, and consider horizontal grid mainly.
4) Set SVM to ON, check the whole effect.
b) Dark current (SCREEN voltage) adjustment
In TV mode receive gray scale signal, after entering into factory menu status, press “1” button to
enter into “FACTORY MENU 1” factory menu, first preset WHITE-R, WHITE-G, WHITE-B’s
value all to 0, adjust SCREEN potentiometer to make SCREEN LOCK on the screen lower part
display OK and it is OK, at this time, if changing channel, it should not appear flyback line. This
state should also be OK after finish adjusting the white balance.
c) White balance adjustment
Adjust on the basis of the above step, at standard status use gray scale signal to adjust.
1 Press “1”button to firstly adjust TV input white balance: fix the testing point at about 40 nits gray
scale, then by adjusting WHITE-R,WHITE-G and WHITE-B to make the value meet chart 3’s
requirement.
2 Press “5” button to adjust YpbPr input white balance: use oscilloscope to measure Y signal
output on Digital Processing Board. Adjust G-0 gray scale to make blanking level be even with
black level, adjust G-G to make signal amplitude to be 0.7V and eight level gray scale be even,
then adjust R-G, B-G, R-0, B-0’s value to make white balance meet chart 3’s requirement.
d) Picture size position and high voltage adjustment
In component mode input 1080I signal
Use crosshatch and electrical circle signal, after entering into factory menu status, press “2”
button to enter into “FACTORY MENU 2” factory menu to adjust picture’s linearity. Adjust
R339 joint point to make the V-center deflection range be within ±5MM(T3251), or
±3MM(T2751).
Change the signal to white background, or greatly change contrast and brightness, or press
PIC button to switch among several kinds of analogue amount to make corresponding beam
current changes, adjust V-EHT-COM, H-EHT-COM to make raster’s size basicly not change
when at different beam current status.
3) According to chart 2 in turn apply every testing signal (firstly apply YpbPr signal, then TV or AV
signal), then press “5” button to enter into “FACTORY MENU 5”, adjust H-S, V-S, H-SIZE, V-SIZE to
make picture normal.
e) Sub-brightness adjustment
Receive split field signal, set colour/contrast/brightness to 0, check whether screen second gray is
slightly bright, otherwise press “6” button, in factory menu select CONTRAST MAX and BRIGHT
MAX to adjust.
f) Filament/beam current/high voltage check and adjustment
1) Filament voltage: receive a TV program signal, set picture mode to “STANDARD”,the filament
voltage effective value should be 6.3 0.2 Vrms.
2) Beam current check: receive all white field signal, set picture mode to “SPORTS”, measure
R360 two terminals’ voltage and the reading should be less than or be equal to 1.6V. If not,
after entering into factory menu status, press “4” button to enter into “RGB MENU” factory
menu, adjust AV BEAM LIMIT item to make beam current meet requirements.
3) High voltage check: receive D8 signal, set picture mode to “STANDARD”, measure CRT high
voltage and the reading should be A value in chart 3. When brightness, contrast is set to
minimum (zero beam current), measure the high voltage,
4) High voltage protection: receive a picture signal, adjust until picture and sound are normal,
short R340 and the circuit should immediately enter into power-off protection state and the
state should keep. Turn off the power switch and then turn on, the picture and sound should
restore to before-testing state.
g) Peak value adjustment
On the condition of SCREEN and beam current has been adjusted properly, in order to show
picture’s contrast well and control picture’s colour tail, apply a little beam current picture (for
example, black and white crosshatch) and set picture’s contrast and brightness to maximum, then
after entering into factory menu status, press “4” button to enter into “RGB MENU” factory menu,
by adjusting PEAK DRIVE LIMIT item to make the whole unit’s picture colour just without colour tail
on the condition of maximum contrast and it is OK.
h) Every control buttons’ check
Check according to Instruction manual.
i) Check all the input/output terminals’ function, please check according to “PRODUCTION
STANDARD”
i) Out-factory setting
Set picture to “Standard”.
Set sound to “Music”.
Set Blue back to ON.
Set OSD language to English.
Set DNR to SOFT.
Set SVM to ON.
Set Volume to 30.
Set Loudness to OFF.
Set AVC to ON.
Set CCD to OFF.
Set child lock password, V-chip password to 0000.
Set V-chip all rating to no rating .
Set the channel to Cable 3.

Advent SQ1435A TV Service Menu

Advent TV SQ1435A Service menu

Press DSP, sleep, pict in quick succession. The distance of time hit just 5 seconds and if more can not be entered into the service mod.
Press the button in quick succession with the rapid and after entry into service, please make arrangements for Advent TV SQ1435A yours.
To set and select parameters use the program up and down and to make changes in the parameter values please use the volume keys up or down.
After the settings according to your expectations and will be out of fashion serivice TV Advent SQ1435A yours, please press the MENU button.

Advent SQ1435A TV Service Menu

Photo credit : lighthom.com
