Before you entering China LCD and CRT TV factory mode to change any value on the factory service mode, please write down all the original factory settings. tvservicemenu are not responsibility for any damage, data error and unwanted effect after using our service code and information on these page.
China LCD (Liquid Crystal Display) and CRT
China TV using TDA93412NC IC
You can use tv remote or universal remote.
Press Menu - display a picture menu and enter the code 6 4 8 3 - M symbol displayed on the screen.
To exit the factory mode and return to normal press Power button on the remote control.
In factory mode {"M" mode) there are 10 menu entirely. Menu 1 and Menu 4 can be selected directly, but the menu 5 and Menu 0 must choose the steps: Press CALL, to call the "M", press LOCK, then press any of the numeric keys 5 to 0.
For example, to select Menu 7, you must press the LOCK CALL and turns and then press 7.
Photo by www.lg.com
Press CALL, PRESS MUTE and 980 codes. In the upper left corner there is a symbol of M.
Chassis HAIER
TDA9370PS / N2 / AI0961 24c08
Press QV hold about 4 seconds and then press the button on the remote control Menu1.
Press the TEST button on the RC unit for factory use.
The "TEST" is displayed on the screen. Digital Press, (Mkey) and corresponding on-screen display will appear.
Some time "PASSWORD" will appear on-screen display, you need to enter 828.
TDA9384PS / N2 / 31FM-OSD and use memory 24c08
Press sequence CLOCK, pm, TIMER (DISP)
Press 0 - 9 to select MENU
To enter the factory mode press SUB PAGE button on the remote control, while you press the volume down (Vol+)
Chassis UOC -TDA9381 (C312)
Press the "MENU" Button button and press the code 8,5,0,0. of M symbol will show In the upper left corner. Select the desired menu press 0 to 9 following your own chose.
TDA9381C38ND
OM8370-B-16NB
China TV use LC86332A-51C7 IC
Press the holes that are already available in the remote
Press the MENU 8 6 3 3.
China TV LC86332B - 52Z6, 53L1
Press the holes that are already available in the remote
Press the MENU 8 6 3 3 or 6 4 8 3.
Chassis 3Y11 / 3Y01 / 4Y01 LC863324A-5S68
Press MENU 2 times - RECALL, QView, MUTE
UСom ST6-ELAME2
Click the button: SKIP, Volume down - FINE TUNE
LC863532A-57P1 -57Z0
Two ways to enter service mode
#1. Press the hidden button located above. If the hidden button is missing, by opening the control panel, find the contact that led to the closing of two SERVICE menu. Standard matrix, 8x4, usually entered BUS press P + P-STBY and 9.5, Sleep
#2. Clicking the MENU button three times to enter the Settings page. Press P + or P- select SWITCHING line. Dial the code "2483." TV enters the PAGE MENU. Turn the page menu button press MUTE PAGE, Disable Vertical - TV / AV. To enter the service menu of 3 or higher, you must set the OPTION PAGE 1.
LC863328A 5W63, 52E5, 56C9 / LC863320A-5R76
Press RECALL , press Volume down on the panel while hold press RECALL
Chassis 502 LC863532 - 54D5, 54H7, 5Z00, 50S8, 50S9, 52Y7
Two metod to enter factory mode
# Plug in the supplied remote hole
# Atur volume 0, press MENU 6 5 6 8.
Chassis 3S10 ST92185BN4B1 / PBI - 3S10B-ENG / RUSS W / O
There are two ways to enter the service mode:
Press the hidden button and the MENU button on the right of
Press and hold the MENU button on the order of AV ANAL
Pressing OK will enter the group option.
For IAC 2000 code: 1124, with MENU = MENU, AV = AV, ANAL = CHIFT + B, OK = MUTE, PP = CHIFT + OK.
To exit the service menu you have to click on the TV or PP.
Chassis PT90, ST92195C7B1 / MIF, ST92195C7B1 / PFT
Turn on your TV.
Select FEATURES MENU.
Dial code 1923
TMP87CM38N -2A55, -3GG3
Adjust volume to 0, press Volume down on TV panel and hold it while pressing the CALL / disply on the remote control. The screen will display the symbol D. D symbol is a simple factory S mode, which is available to the factory mode from the menu 0, 1 and 2. To enter the Factory mode is extended to S mode, press SYSTEM.
MCL437F, TMP87CK38N-1A72
Press the MUTE button on the remote control is released, press MUTE again and hold it while you press MENU on the TV.
The screen will display the symbol D. This is a simple service mode S. To enter the service mode is extended to S mode, repeat the operation. The screen will display the symbol D.
TMP87PS38N-M13VR2V1
Press volume down on television panel until the colume decrease to 0 and hold while you press DISPLAY on the remote control.
The screen will display D symbol , This is a simple S factory mode . To enter the service mode is extended to S mode, repeat the operation. The screen will display the symbol D.
The transition between the two groups through the DISPLAY menu. Selection of options and make a determination of Channel up, Channel down, volume up and volume down.
TMP87CM38N-3GN5, TMP87CK38N-2B46, Chassis TB1238
To enter the service mode via the following procedure:
Press for the introduction of double - digit , channel -/-- number and program 12.
After the transition, select program 38.
Channel 38 MENU button a second menu with POS.LOCK.
Press MUTE. The first sign that everything is done correctly there will be an indication of muting
Enter the password 1 2 3 8. TV will go into service mode and the screen displays the M symbol.
(The latest model of entry into the service mode for multiple versions of the processor has been simplified to a standard for Changhong - at zero volume.)
TDA9353PS / N1 / 2S0511
TDA9351PS / N2 / 2I0927
TDA9353PS / N1 / 3S0342
TDA9350PS / N1 / 2S0512
TDA9380PS / N1 / 1L0231
TDA9360PS / N1 / 4S0415
TDA9360PS / N1 / 4S0430
TDA9353PS / N1 / 2I0269
TDA9350PS / N2 / 2I0851
TDA9350PS / N1 / 2L0296
TDA9350PS / N1 / 2K0172
TDA9350PS / N1 / 2K0223
TDA9353PS / N2 / 2I1186
TDA9351PS / N2 / 2I1192
TDA9353PS / N1 / 2L0297
TDA9350PS / N1 / 2S0296
TDA9350PS / N1 / 2S0510
TDA9350PS / N1 / 2S0546
TDA9353PS / N1 / 2S0596
TDA9353PS / N2 / 2I0869
